The membrane has high strength, no filament, and strong anti-peeling strength
The filter layer has good hydrophilicity and asymmetric structure
The membrane pore size is 0.02µ m
Chemical resistance cleaning
Suitable for industrial sewage using MBR, MCR
|
Model |
LJ1 E3-950-PF |
LJ1E3-1500-PF |
LJ1E3-2000-PF |
LJ1 E2-2000-PF |
|
External dimensions (mm) ( L×W × H ) |
721 x 70 x 1082 |
721 x 70 x 1622 |
721 x 70 x 2122 |
721 x 70 x 2122 |
|
Effective membrane area(m²) |
1 4 |
23 |
31 |
25 |
|
Water inlet interface (mm) |
Φ37.4×2 |
Φ37.4×2 |
Φ37.4×2 |
37.4×2 |
|
Weight (kg) dry weight |
9 |
13 |
1 6 |
15 |
