Reduce the air-water ratio to 6:1, saving more than 40% energy compared with the conventional type
It has better aeration and blowing effect
More suitable for medium and large projects
It can be replaced with PM material ultrafiltration membrane for higher cost performance
|
Model |
LG J2E-2000X20A |
LG J2E-2000X40A |
|
External dimensions (mm) ( L × W X H ) |
2120 x 884 x 2850 |
2120 x 1700 x 2905 |
|
Effective membrane area(m²) |
1040 |
2080 |
|
Number of membrane elements (curtain) |
20 |
40 |
|
Water inlet interface (mm) |
DN100flanges |
DN100flanges x2 |
|
Inlet interface (mm) |
DN65flanges |
DN80flanges |
|
weight (kg) Dry weight (moist weight) |
1000 (2250) |
1900 (4300) |
