The FSHB-150 is a highly integrated modular RO system designed for medium-scale projects with high demands for space economy and operational cost-effectiveness. It delivers 150 tons of high-quality freshwater daily with only 37kW power consumption, all within an extremely compact footprint (approx. 5.9m L x 2.4m W x 2.4m H).
It inherits the reliability of the series, utilizing efficient RO membranes and energy recovery to achieve 99.2% salt rejection and a 35% recovery rate with low energy-per-ton consumption. It adapts to complex feed water up to 40,000 ppm TDS, offering a cost-effective solution for island developments, medium industrial projects, and community supply.
Compact & Efficient: Integrated skid design saves space, facilitates transport/installation; 37kW low-power operation cuts long-term costs.
Stable, High-Quality Output: 150 TPD with stable >99.2% salt rejection ensures reliable water quality (TDS <700ppm).
Wide Environmental Tolerance: Handles high-salinity feed (TDS ≤ 40,000 ppm), pH 3-10, and operates in 5-45°C.
Plug-and-Play, Easy Maintenance: Factory-tested for quick commissioning; modular design simplifies upkeep.
Global Voltage Support: Compatible with 380V/50Hz, 440V/60Hz, 480V/60Hz standards.
Medium Islands & Communities: Stable water for hotels, resorts, and small residential areas.
Industrial Support: Process water for medium food processing, beverage production, light manufacturing.
Ships & Marine Platforms: Freshwater self-sufficiency for large ships and offshore platforms.
Emergency & Mobile Supply: Modular equipment for disaster relief or temporary camps.
| Parameter | Specification |
| Fresh Water Capacity | 150 tons/day |
| System Recovery Rate | 35% |
| Salt Rejection Rate | ≥ 99.2% |
| Product Water TDS | < 700 ppm |
| Working Pressure | 3.5 – 5.5 MPa |
| Installed Power | 37 kW |
| Input Voltage | 380V/50Hz, 440V/60Hz, 480V/60Hz |
| Feed Water Quality | TDS ≤ 40,000 ppm, pH 3-10 |
| Operating Temperature | 5 – 45 °C |
| Dimensions (L×W×H) | 5898 × 2352 × 2385 mm |
| Net Weight | Approx. 6,000 kg |
| Gross Weight (Packed) | Approx. 7,500 kg |
Fresh Water Output: 320 tons per day System recoveryrate:35% Power Consumption :75KW Voltage:380V/50HZ,440V/60HZ,480V/60HZ...
Fresh Water Output: 240 tons per day System recoveryrate:35% Power Consumption:52.5KW Voltage:380V/50HZ,440V/60HZ,480V/60HZ...
Fresh Water Output: 100 tons per day System recoveryrate:35% Powerconsumption :30KW Voltage:380V/50HZ,440V/60HZ,480V/60HZ...
Fresh Water Output: 60 tons per day Size:L*B*H=2250mm*1250mm*2040mm Weight:≈ 2500kg (dry weight) Power...
Fresh Water Output: 50 tons per day System recovery rate:35% Power Consumption :18.5KW Voltage:380V/50HZ,440V/60HZ,480V/60HZ...
Fresh Water Output: 25 tons per day System recoveryrate:25% Power Consumption :5.5KW Voltage:440 V/60...
Fresh Water Output: 20 tons per day System recovery rate: 35% Power Consumption: 10KW Voltage: 380V/50HZ,...
Fresh Water Output:10 tons per day Size: L*B*H=1520mm*800mm*1920mm Weight: ≈800Kg (dry weight) Power...
Main features: compact structure, generous; Easy to operate and maintain. Fresh Water Output: 5 tons...
Fresh Water Output: 1.5 tons per day System recovery rate:12% Power Consumption :1.5KW Voltage:single-phase220V/50HZthree-phase...
A: You receive comprehensive water treatment services including detailed system documentation, operator training, warranty coverage, and access to our technical support team. We also offer optional annual maintenance contracts for long-term industrial water system support.
A: We maintain strategic inventory of critical water treatment spare parts. For urgent needs, we expedite shipping to minimize your RO system maintenance downtime. Our support team manages parts identification and logistics.
A: We prioritize emergency cases. For critical issues halting operation, we provide initial response within 4-8 business hours and work relentlessly to resolve problems, leveraging remote diagnostics for water treatment maintenance.
A: Yes. We offer comprehensive training during water plant commissioning, covering normal operation, routine water treatment maintenance, and basic troubleshooting procedures.
A: Absolutely. Our systems feature modular design. We can reassess needs and provide retrofit solutions or capacity expansions through our water treatment services to adapt to changing conditions.
